Nominal Size: 1/8~3/4”(DN3~DN20)
Working pressures up to 3000 psig (207 bar)
Temperatures up to 375°F (190°C)
Open pressure: 0.7~25psig(0.05~1.7bar)
Body Material: 316SS, Alloy 400, Titanium alloy available.
Seat Material: FKM, NBR, EPDM, Viton, CR available.
End Connection: Tube fitting, Male and female NPT and ISO pipe.
